Sand Making Machine

Sand Making Machine

Feeding Size ≤50mm
Processing Capacity 60-600t/h

PRODUCT INTRODUCTION

VSI series vertical shaft impact crusher (new type sand making machine) is a high-level sand making machine developed after several technical improvements based on the introduction of advanced German technology by our company and the actual situation of domestic sand making production. equipment. The equipment is especially suitable for providing sand and gravel aggregates for high-rise buildings, highway (railway) construction, municipal engineering, large-scale water conservancy facilities, concrete mixing stations and many other fields.
It is the key equipment for artificial sand making to provide high quality sand aggregate for building, highway, construction, concrete batching plant, etc.
The hot sale sand making machine includes artificial sand making machine, silica sand making machine, plaster sand making machine.
We also provide complete sand making production line, which includes sand making machine, sand washing machine, sand screen machine, vibrating feeder, belt conveyor,etc.

0-5mm、5-10mm、10-20mm、20-50mm

It can crush more than 100 kinds of rocks. The common discharge size is...

Features

High yield and good grain shape

Large processing capacity, high output, cubic product, good grain shape, reasonable gradation, adjustable fineness modulus, especially suitable for artificial sand making and stone shaping, compared with traditional equipment with the same power, the output is increased by 30% .

Good energy saving effect

The parts of the equipment adopt new design and materials, which are not only wear-resistant but also more convenient to use with the whole machine.

Wide range of applications

VSI sand making machine is easy to operate and energy-saving, which not only meets the quality requirements of construction sand, but also makes up for the technical defects of the sand making industry, and can be combined and classified according to the different needs of users, which can meet the different process needs of users.

Thin oil lubrication, automatic maintenance

The German original thin oil lubrication station is used, and the double oil pumps complement each other to ensure oil supply, no oil flow, and automatic shutdown when there is no oil pressure; oil cooling and heating devices ensure that the bearing lubrication is always in good condition, so as to completely solve the problem of bearing heating, so that the main shaft bearing Maintain a constant temperature for extended maintenance intervals and service life.

WORKING PRINCIPLE

VSI vertical shaft impact sand making machine uses high-speed moving materials to crush each other and the friction between materials. The material falls into the feeding hopper of the sand making machine, enters the high-speed rotating wheel through the central feeding hole, is rapidly accelerated in the wheel, and its acceleration can reach dozens of times the acceleration of gravity, and then is ejected from the wheel at high speed. Another part of the material that falls freely after the rebound hits, and then hits the material lining (stone hits stone) or counterattack block (stone hits iron) together, and is rebounded and hits the top of the vortex chamber obliquely upward, and then changes its movement direction, deflecting to It moves downward and collides with the material emitted from the impeller channel to form a continuous material curtain. In this way, a piece of material is subjected to two or more chance impacts, friction and grinding and crushing in the eddy current crushing chamber, and the crushed material is discharged from the lower discharge port.

Product Photos

technical specifications

Model VSI-7611 VSI-8518 VSI-9526 VSI-1140
Capacity(t/h) Cascade and Center Feeding 120-180 200-260 300-380 450-520
Center Feeding 60-90 100-130 150-190 225-260
Feeder Opening Size (mm) Soft Material ≤35 ≤40 ≤45 ≤50
Hard Material ≤30 ≤35 ≤40 ≤45
Rotation Speed 1700-1890 1520-1690 1360-1510 1180-1310
Power of the Double Motors(kw) 110-150 180-220 264-320 400-440
Overall Dimension(mm) 3700x2150x2100 4140x2280x2425 4560x2447x2778 5000X2700X3300
Weight (t) 7.8 10.3 16 25.6
Power 380V:50Hz
Vibrating Sensor Inspection Scope: 0.1-20mm/s,it can be adjusted continuously
Thin oil lubrication station Power of Double Oil Pump 2×0.31kw
Safety supply of oil; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter
Overall Dimension (mm) 820×520×1270
Power of Oil-box HeaterDimension (kw) 2KW
